Automatic High Speed Shrink Label Inserting with Shrink Tunnel SleevPACK-300

The Automatic High Speed Shrink Label Inserting Machine ModelSleevPACK-300 with Option of Shrink Tunnel is suitable to Insert ShrinkLabel on Glass, Plastic, PET, Aluminium Bottles and Containers in FOOD,FMCG, Pesticides, Cosmetics and Pharmaceutical Industries. The Machineincorporates latest sophisticated SERVO Control Sleeve Applicator. TheMachine Construction in Heavy Duty S.S.304 Material but with Compactdesign.

This Flexible Sleeving Machine is suitable for decoration of wide range ofRound Bottles and Containers. Special machine also available for specialshape containers. Machine can give speed upto 300 Bottles per minutedepending on Sleeve Cut Length, Shape of Bottle and Shrink percentage ofSleeve. Machine with Optional Pre-Fixing Hot Air Nozzle for Setting SleevePosition at Top or Bottom of Bottles before entering into Shrink Tunnel.

Sleeving Machine having Time Tested Rotating type SERVO ControlledSleeve Cutting System for high Speed and accurate sleeve cutting. Machineis ideal to use on Round and other curve shape Bottle or Containers whereSticker Labelling is not possible to use.

  • Category : Shrink Sleeve Machines
  • Modal : SleevPACK-300

Technical Specifications :

- Sleeve Height : 50 mm to 150 mm Standard*

- Bottle Height : up to 225 mm

- Sleeve Roll Dia. : 400 mm

- Core Dia. : 75/76 mm

- Sleeve Thickness : 0.045mm to 0.08mm

- Product Diameter : User can choose any one option 25 to 50mm / 45 to 90mm or 90 to 125mm*

- Electrical : 415 VAC 3 Phase Power Supply (50/60 Hz)

- Power : 2.5 Kw for Machine and 20 Kw for Shrink Tunnel

- Speed : Up to 300 Products per minute depending on Product Diameter, Product Height and Sleeve Cutting Length.

- Conveyor height : 900 to 950 mm*

- Overall dimension : 2440 mm(L) X 1000 mm(W) X 1900 mm (H)

- Machine with Shrink Tunnel : 4880 mm(L) X 1000 mm(W) X 1900 mm (H)

- Machine Direction of Movement : Left to Right from operator side

Specification can be changed as per customers requirements

Special/Optional*Features :

- Tower Light showing the machine status / operation

- Vision System for checking Presence / Absence of Sleeve on Bottle

- Infeed Jam detection system

- Outfeed Jam detection system


Built-in-Unique Features :

- Colour Touch Screen Operation Panel with PLC Control

- Virtually Maintenance Free Machine

- Synchronized speed of Sleeve Dispensing, Conveyor and Sleeve Positioning Device.

- Easy to change Sleeve application height

- Heavy Duty S.S. 304 Material Machine Frame Structure

- S.S.304 Material heavy duty Safety Cabinet with Toughened Glass

- Built In A.C. Variable Frequency Drive System.
