Technical Specifications :
-Printing System : Thermal Transfer Printing Technology
-Label Height : 150mm Standard*
-Label Length : 300mm Standard*
-Print Resolution : 203 dpi (8 dots/mm) , 305 dpi (12dots/mm)
-Media Width : 177mm Max.
-Gap Between two Labels : appx. 3 mm or more
-Font Specification :
Internal Fonts:
-Bitmap :U,S, M,WB, WL, XS, XU, XM, XB, XL,OCR-A,OCR-B, Chinese(GB18030, BigS), Korean (KSX1001)
-Scalable :CG Times,CG Triumvirate™, SATO GAMMA, SATO VICA, Thai,Arabic
-Downloadable fonts support : Bitmap,True Type (1byte/2byte), Maximum 11.7MB
-Electrical : 220 VAC Single Phase Power Supply (50/60 Hz)
-Power : 1.0 Hp, 2.0 Amp.
-Capacity : 0.75 Kw
Speed : Up to 20 Labels per minute depending on Product and Label Size
Specification can be changed as per customers requirements
Special/Optional*Features :
- Suitable for TOP or Side Application
- Side Application is optionally available to apply Side Label or Side Label in “L” shape covering two panel
- Machine construction in SS304 material
- Suitable to connect with Database server for downloading data to be print with help of software
- Heavy Duty Mounting system for Print Engine with Trouble Free long term operations.
- Suitable to Print Static Data as well as Variable data
- Suitable to use for Track and Trace application with help of required optional software.
- 21 CFR Part 11 Compliance available as optional.
Utility Required :
-Power : 2.0 Hp
-Electrical : 220 VAC 1 Phase Power Supply (50 Hz) or415VAC 3Phase
-Compressed Air : 5 - 6 Bar
